Product Details:
|
| Type: | Module/Enclosed | ||
|---|---|---|---|
| Highlight: | Communication cofdm transmitter,Anti Jamming cofdm transmitter,Cofdm radio router |
||
|
ALL MODELS
|
|
|
|
Operational Modes
|
Async.-Simplex, half-duplex,(synchronous available (9600bps only) in MDS 4710B, and MDS 9710B)
|
|
|
Data nterface
|
RS-232-485,DB-25(x710)/Layer 2(or 3) IP,RJ45(x710IP) transparent transmission
|
|
|
Transmitter
|
|
|
|
Frequency Stability
|
+/- 0.00015% 1.5ppm
|
|
|
Carrier Power
|
0.1 to 5watts/5 to 25watts Programmable
|
|
|
Carrier Power Accuracy
|
Normal +/- 1.5dB
|
|
|
Duty Cycle
|
Continuous
|
|
|
Output Impedance
|
50 Ohms
|
|
|
Receiver
|
|
|
|
Type
|
Double Conversion Superheterodyne
|
|
|
Frequency Stability
|
+/- 0.00015% (1.5 ppm)
|
|
|
Adjacent Channel (EIA)
|
60dB nominal
|
|
|
Power Supplies
|
|
|
|
Primary Power
|
Voltage 13.8Vdc nominal(10.5 to 16 Vdc operating range)
|
|
|
Tx Current
|
2A Typical at 5watts/5A Typical at 25watts
|
|
|
Rx Current
|
＜125mA
|
|
|
Sleep Mode:
|
15mA nominal
|
|
|
Modem / Diagnostics
|
|
|
|
Modulation
|
Digital/CPFSK
|
|
|
CTS Delay
|
0-255msec programmable in 1 msec increments
|
|
|
PTT Delay
|
0-255 msec programmable in 1 msec increments
|
|
|
Physical
|
|
|
|
Case
|
Rugged Die Cast Aluminum
|
|
|
Dimensions
|
5.1x14.3x18.4cm
2.5x11.9x15.8cm
|
|
|
Weight
|
1000g,148g
|
|
|
Environmental
|
|
|
|
Temperature Range
|
-40°Cto +70°C(-40°F to +158°F)
|
|
|
Humidity
|
95% at 40C (104°F) non-condensing
|
|
|
Price(The specifications are different, the price is different)
|
|
|
|
WDSx710
|
$500/unit
|
|
|
WDSx710IP
|
$600/unit
|
|
