Product Details:
|
| Type: | COFDM | ||
|---|---|---|---|
| Highlight: | COFDM ip radio modem,Long Distance ip radio modem,COFDM ip radio network |
||
|
Operating Frequency
|
300-350MHz or 560-610MHz (200MHz-2.7GHz can be customized)
|
|
|
Transmitting Power
|
1W/5/10W
|
|
|
Receiving Sensitivity
|
-106dBm@2MHz
|
|
|
Modulation Coding
|
QPSK/16QAM/64QAM
|
|
|
Rf Bandwidth
|
2-8MHz adjustable
|
|
|
Transmission Stream
|
2-20Mbps adaptive
|
|
|
Forward Error Correction
|
1/2,2/3,3/4,7/8
|
|
|
Protection Interval
|
1/4,1/8,1/16,1/32
|
|
|
Carrier Number
|
2K
|
|
|
Power Flatness
|
Less than 0.2db in 10MHz band
|
|
|
Shoulder Ratio
|
When the output power is 27 dB, the band to shoulder ratio is better than - 30 dB
|
|
|
Second Harmonic
|
≤ -65dB
|
|
|
Mer
|
32dB
|
|
|
Transmission Distance
|
1w: above 20km, 5W: above 50km,
10W: above 100km (sight distance)
|
|
|
Video Input
|
HDMI/SDI/CVBS:720x480 60I(NTSC),720x576 50I(PAL),720 50P,720 60P,1080 50I,1080 60I,1080 24P,1080 50P,1080 60P(CVBS video input N/P
adaptive) |
|
|
Video Output
|
HDMI / RJ45 IP simultaneous output
|
|
|
Video Stream
|
2-20Mbps(H.264/H.265)
|
|
|
Video Input Interface
|
HDMI/CVBS (Low latency)
|
|
|
Video Output Interface
|
HDMI
|
|
|
Video Coding Format
|
H264+(HDMI)/H.265(CVBS)
|
|
|
System Delay
|
Less than 180ms(CVBS end-to-end low latency less than 120ms)
|
|
|
Video Delay
|
Less than 250ms
|
|
|
Encryption Method
|
128 bit AES encryption
|
|
|
Protection Standard
|
All aluminum radiator shell, anti rust, shockproof design
|
|
|
Operating Temperature/Voltage
|
-30℃~+70℃,11-16V
|
|
|
Operating Current
|
1W/Receive/5 W/10W/CVNS 3W Receive: 1.3A/0.35A/2.8A/5.9A/1.7A@12V)
|
|
|
Overall Dimension
|
1W/Receive/5W/10W/CVBS3W Repeat: 10.8x8.2x2.8/13.6x11.7x3.4/10.8x9.0x2.8/19.6x14.6x3.4/6.7x4.8x2.3cm
|
|
|
Weight
|
1W/Receive/5W/10W/CVBS3W Repeat: 233g/425g/289g/990g/80g
|
|
|
Control Interface
|
Standard RS232 interface, 8-bit data bit, 1-bit stop bit, even-check, baud rate: 19200
|
|
|
Transparent Data Interface
|
A unidirectional transparent serial port transmission, 8 data bits, 1 stop bit, support odd check, even check, wireless check,baud rate: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400
|
|
|
Built-In Bidirectional Data Transmission Module
|
410-480/840-845/902-928MHz, 3.6-19.2kbps conventional/ 19.2-230.4kbps frequency hopping, 1-2W, TTL/232/485/422, 3.3-30VDC
|
|
|
Power Consumption
|
≤ 15W (1W radio), ≤ 35W (5W radio)
|
|
|
Price(The specifications are different, the price is different)
|
|
|
|
1Watts HDMI
|
$2150/pair
|
|
|
5Watts HDMI
|
$2850/pair
|
|
|
10Watts HDMI
|
$3570/pair
|
|
